QUADROplan

Optimally planned – optimally utilised

QUADROplan software product packaging

Project planning Industry 4.0

QUADROplan is a modern CAD software

…which optimally supports architects, developers and construction companies in the planning and implementation of construction projects in the QUADRO system. Get started today and make your masonry implementation more efficient than it was yesterday.

Download the free demo version →

Brickwork implementation

The software has been specially optimised for the masonry element of QUADRO and its various variants. The close cooperation with the sand-lime brick manufacturers ensures that both the standard QUADRO system and QUADRO E and QUADROTHERM, if desired also with chimney blocks for length compensation, can be planned in a practice-oriented manner.

An open platform

QUADROplan is based on the general software Wandplan. Wandplan is an open platform for building structure-oriented modelling in building construction. Many well-known companies in the construction materials industry already work successfully with Wandplan – including the majority of sand-lime brick manufacturers.

A high degree of automation

is an essential feature that makes working with QUADROplan efficient. All building structures relevant for masonry elementation are displayed as independent objects and can be edited independently of each other.

Extensive evaluation options

are available to the user at the touch of a button – completely dimensioned floor plans, clearly laid out installation plans, sectional plans and mass determination, with display of e-channels if required.
